VAP11G-500
Hits:433

  VAP11G-500 is a professional 300M Mini High-power WiFi repeater, that is elaborately developed by HouTian Network, the original creation D/A temperature compensated auto frequency control technology(TAFC), it solved the common failing of the traditional WiFi router or WiFi products that easily drop the network, the lasting stability makes sure that the WiFi signal is not dropped.  It is based on IEEE 802.11N standard, compatible with IEEE 802.11B and IEEE 802.11G standard.It can extend the range of WiFi networks, providing up to 300Mbps the stable transmission rate.

   1. Environmental, Safe, Portable, Mini;
   2. Support 802.11b/g/n WiFi transmission protocol, the transmission rate is  300Mbps ;
   3. The transmission distance (without obstacle) : 500M;
   4. Support RF general power(15dBm) and high-power(20dBm) optional;
   5. Input voltage(DC5V-15V), Needn’t extra power supply,  reducing e-waste;
   6. Professional smart WiFi repeater;
   7. WiFi smart bridge function, WiFi to wired, wired to WiFi, smart exchange;
   8. WiFi smart repeater mode, it supports WiFi hotspot scan automatically and WiFi hotspot memory function;
   9. Support WEB remote firmware upgrade, free to get the latest firmware;
   10. Support WEB management, Chinese and English configuration interface;
   11. Using USB for power ,also convenient to use power bank for power;
   12. Adopt the original creation D/A temperature compensated auto frequency control technology (TAFC ), the lasting stability ensure that the WiFi signal is not dropped;
   13. Original creation VDNS virtual domain configuration technology to solve the  user’s trouble of configuration;
   14. WiFi hotspot memory, maximum memory 100 hotspots;
   15. Support connecting more than 20pcs WiFi terminal at the same time;
   16. Support WPA-PSK/WPA2-PSK, 64/128/WEP security mechanism;
   17. The best partner of remote monitoring, long range WiFi signal coverage.

Hardware Specifications

Protocol Standards

 IEEE 802.11gIEEE 802.11bIEEE 802.11n

Transmission rate/power

 300Mbps / 20dBm

Interface

 1 DC2.0 power hole;

1dedicated two in one power supply cable, with a set of power

supply and a set of 10/100m adaptive Ethernet cable.

 Button

 Reset button (long press 5 seconds)

LED

 Status instruction:

WiFi Status light (blue light);           Ethernet (light green for success);

Antenna

 Built-in smart omnidirectional  antenna

Size

 90mm x 45mm x 15mm (L x W x H)

WiFi Related

Basic function

 Channel option1-14;

WiFi Hotspot scan automatically;

WiFi Hotspot memory.

Power choicenormal power and high-power modes

Working mode

 WiFi smart repeater mode;

Repeater(WiFi signal repeater) modeextend the transmission distance of WiFi;
 WiFi smart bridge mode:
 AP Client (WiFi client) modesuit for IP camera;

WiFi Security

 64/128/WEP encryption;

WPA-PSK/WPA2-PSKWPA/WPA2security mechanism.

System Function

Device reboot;

Reset factory;

Administrate account and password revise;

Firmware upgrade;
