VHA300
Hits：4603
1.1 Hardware features
- Main chip: MT7620N, clocked of main chip: 580MHz;
- 32Mb SDRAM,can be extended 64Mb; 4Mb SPI Flash, can be extended 8Mb/16Mb(Byte);
- WiFi working frequency: 2.4GHz，2T2R dual antenna，MIMO technology 300Mbps transmission rate;
- Support 1-14 WiFi channels;
- The average power consumption is less 0.9W;
- Output power of Module RF :15dbm--16.5dbm;
- Adopt the original creation D/A temperature compensated auto frequency control technology（TAFC）,make sure the lasting stability to ensure that the WiFi signal is not dropped.
- Support 802.11b/g/n mode;
- Operating ambient temperature:-25℃ ---- 55℃.
1.2 Function Features:
- Two switch controlled operating mode: Router mode, WiFi repeater
mode (including bridge mode); ; - Support intelligent transparent bridge mode, also support AP Client and AP Station, facilitate the establishment of tree WiFi network to solve a small star traditional WiFi network coverage problems, make the same WiFi network as ZigBee, smart home system can be easily applied, and WiFi network as a standard IP networking, and its control , communications, development was significantly better than ZigBee;
- Built-in WEB configuration services, available configure module parameters through the web;
- Support VDNS technology, in bridge mode, can be configured via logging on the domain login page, solve the problem that configure and secondary development;
- Support firmware upgrade online;
- Support open-wrt-2.6.36 for VONETS, facilitate open-wrt lovers to
develop various types of WiFi products; - Built-powerful VNET-FREE smart home control protocol service software,
no need to change the module software, simply press the VNET-FREE
Mobile APP to control protocol design software, you can achieve all kinds
of WiFi smart home products;
